Multiple Safety Protection For The LiFePO4 Battery
The 14.6V 10A LiFePO4 battery charger has four protections to protect the battery and charger during the charging process: over-temperature protection, output short-circuit protection, output over-voltage protection, and reverse polarity protection.
Activate Your "Dead" Battery
Equipped with the lithium battery activation function, this portable battery charger can reactivate the battery when the BMS of the lithium battery triggers the protection.
Easy To Use & Clear LED Indicator
It's easy to use this charger to charge the LiFePO4 battery, you need to connect the alligator clip of the charger to the battery terminals and then connect the charger to the power supply. The LED indicator can show the charging status intuitively.
Alloy Material Shell & Robust Crocodile Clip
Intelligent 3-Stage Charging Mode
Dedicatedly designed for LiFePO4 battery, the 14.6V 10A charger has a 3-stage intelligent charging mode (pre-charge, CC, and CV). The pre-charge stage will activate the battery and transition to the constant current stage smoothly. During the constant voltage stage, the charging current will gradually decrease and automatically turn off the output voltage.
Why Timeusb LiFePO4 Battery Charger?
This 14.6V 10A lithium battery charger is specifically designed for LiFePO4 batteries, made of high-quality material with a competitive price. Its multiple protections and smart 3-stage charging mode are good for the battery and charger.
PACKAGE CONTENTS
1 x 14.6V 10A Battery Charger
1 x User Manual
1 x AC Power Cord
Technical Details
BASIC
Charger Type：
LiFePO4 Battery Charger
Output Voltage：
14.6V
Output Current：
10A
Max Input Current：
2.2A
Lithium Battery Activation：
✔
Input Voltage Range：
AC 100V to 240V (45Hz to 60Hz)
LED Indicator：
LED always on red: Battery is charging; LED always on green: Battery is fully charged; LED flashes green: Charger is on standby; LED flashes red: Charger fault or under protection (overtemperature protection, output short-circuit proctection, reverse polarity connection protection, output over-voltage protection).
PROTECTION
Over Temperature：
✔
Output Short-Circuit：
✔
Reverse Polarity Connection：
✔
Output Over-Voltage：
✔
TEMPERATURE
Operating：
14℉ to 113℉ (-10℃ to 45℃)
Storage：
-40℉ to 167℉ (-40℃ to 75℃)
OTHERS
Size：
L7.99 x W3.94 x H2.13 in.
Approx. Weight：
3.53 lbs
Warranty：
2 Years
Certifications：
FCC
FAQs
Q: What charger should I use for LiFePO4 battery?
A:
To fully charge a 12V LiFePO4 battery, a charger with a voltage range of 14V to 14.6V is required. Using a charger with a lower voltage will still charge the battery, but it won't achieve 100% capacity.
Q: What voltage should LiFePO4 lithium batteries be charged at?
A:
The appropriate charger depends on the voltage of your LiFePO4 lithium batteries. For 12V LiFePO4 batteries, the recommended charger is the Timeusb 14.6 volts charger.
Q: How to choose the right charger for my LiFePO4 lithium battery?
A:
It's crucial to ensure that your charger provides the correct current and voltage for the LiFePO4 lithium battery you are charging. For instance, you should not use a 24V charger for a 12V LiFePO4 battery. Additionally, it's recommended to use a charger specifically designed for your battery's chemistry. When charging a LiFePO4 battery with a standard lead-acid charger, make sure the charger does not have a desulfation mode or a dead battery mode.
Q: Can I charge a LiFePO4 battery with a trickle charger?
A:
Trickle charging is unsuitable for lithium batteries. Using a trickle charger not designed for LiFePO4 batteries can result in overcharging or damage, as lithium batteries have different charging requirements compared to traditional lead-acid batteries.
And what about a normal charger? For more information, please see the article "Can I Charge LiFePO4 with a Normal Charger?"
Q: How long does it take to charge a 12V 100Ah LiFePO4 lithium battery?
A:
The 14.6V 10Ah LiFePO4 battery charger is specifically designed for LiFePO4 batteries. Due to the low resistance of the lithium cells, the battery can accept the charger’s full output. At a constant current of 10A, it takes approximately 10 hours to fully charge a 12V 100Ah LiFePO4 battery (calculated as 100Ah/10A=10 hours).
