PACKAGE CONTENTS:
1 x 36V 50Ah Trolling Motor LiFePO4 Battery
1 x Product Manual
2 x M8 Terminal Bolts
2 x Plastic Nut Caps
2 x Flat Washers
ATTENTION:
1. A charger is not included.
2. If a bolt is directly fastened or the thickness of the harness OT terminal piece used is less than 2 mm, add a flat washer for fastening.
NOTE:
This battery is not suitable for water pumps, electric jacks, electric stackers/lifts, pool vacuums, or similar loads. If you have any questions, please provide a specific product link, and we will check compatibility for you.
Technical Details
BATTERY
Cell Type：
LiFePO4 Prismatic
Warranty：
5 Years
Cycle Life：
4000 cycles at 100% DOD, 6000 cycles at 80% DOD, 15,000 cycles at 60% DOD
Nominal Voltage：
38.4V
Rated Capacity：
50Ah
Energy：
1920Wh
Max. Expansion (Parallel & Series)：
4P (36V 200Ah)
Internal Resistance：
≤ 40mΩ
Certifications：
FCC/UL1973
BMS
BMS：
50A
Max. Continuous Output Power：
1920W
Max. Continuous Charge Current：
50A
Max. Continuous Discharge Current：
50A
Surge Discharge Current (1 Second)：
250A
Max. Continuous Discharge Current (30mins)：
60A
CHARGE
Charge Method：
CC/CV
Charge Voltage：
43.2V ± 0.6V
Recommend Charge Current：
10A (0.2C)
TEMPERATURE
Charge Temperature：
32℉ to 122℉ (0℃ to 50℃)
Discharge Temperature：
-4℉ to 140℉ (-20℃ to 60℃)
Storage Temperature：
14℉ to 122℉ (-10℃ to 50℃)
Low-Temperature Protection：
32℉ (0℃)
Low-Temperature Charging Protection Auto Recovery：
41℉ (5℃)
OTHERS
Terminals：
M8 bolts
Weight Approx.：
32.96 lbs
Size：
L13 x W6.77 x H8.5 in.
Housing Material：
ABS
Protection Class：
IP65
FAQs
Q: What is the ideal thrust range for a 36V trolling motor battery?
A:
A 36V trolling motor battery is typically suitable for trolling motors with a thrust range of 80 to 120 lbs. This Timeusb 36V 50Ah Trolling Motor battery can support a maximum thrust of 120lbs.
Q: Can I charge Timeusb 36V 50Ah Trolling Motor LiFePO4 lithium batteries in cold weather (under freezing temperatures)?
A:
Sure, Timeusb 36V 50Ah LiFePO4 batteries can charge between 32°F to 113°F (0°C to 45°C), and it has low-temperature charging protection function, it would cut off charging when it's below 0℃.
