More Reliable, Affordable, and Safer
Timeusb 12V 140Ah group 31 deep cycle battery applies Automotive Grade A LiFePO4 Cells, supporting 4000+ cycles life and a 10-year lifespan. Featuring a built-in 100A BMS with 100% protection against overcharge, discharge, over-current, short circuits, high temp, and low temp, this battery ensures more reliability and safety on indoor or outdoor installations and applications.
Stay Charged, Stay Powerful
Recharge Your Timeusb 140Ah Group 31 battery anytime, anywhere. This battery offers flexible, convenient 3 charging solutions, including compatibility with 12V AC-DC chargers, solar panels via an MPPT controller, generators with AC-DC chargers.
Upgrade Your Power System To The Next Level
The Timeusb 12V 140Ah lithium-ion battery can be connected up to 4 pcs in series (4S) or 4 pcs in parallel (4P) for greater capacity. With 16 x 12V 140Ah deep cycle batteries in 4P4S, it delivers a substantial 28.672 kWh of energy and 20.48 kW of power. Ideal for high-demand applications!
Unlock Your Imagination, Go Where You Want To Go
This 12V lithium battery is a versatile power solution suitable for various application scenarios. Whether you are setting up a home solar power system, outfitting your RV, van, motorhome, or camping equipment, powering a trolling motor or boat system, or building an off-grid system, this battery provides reliable and efficient performance.
PACKAGE CONTENTS:
1 x 12V 140Ah Pro LiFePO4 Battery
1 x Quick Start Guide
1 x Product Manual
2 x M8 Terminal Bolts
2 x Plastic Nut Caps
2 x Flat Washers
ATTENTION:
1. A charger is not included.
2. If a bolt is directly fastened or the thickness of the harness OT terminal piece used is less than 2 mm, add a flat washer for fastening.
NOTE:
This battery is not suitable for water pumps, electric jacks, electric stackers/lifts, pool vacuums, or similar loads. If you have any questions, please provide a specific product link, and we will check compatibility for you.
Technical Details
BATTERY
Cell Type：
LiFePO4 Prismatic
Warranty：
5 Years
Cycle Life：
4000 cycles at 100% DOD, 6000 cycles at 80% DOD, 15,000 cycles at 60% DOD
Nominal Voltage：
12.8V
Rated Capacity：
140Ah
Energy：
1792Wh
Max. Expansion (Parallel & Series)：
4P (12V 560Ah) / 4S (48V 140Ah) / 4P4S (48V 560Ah)
Internal Resistance：
≤40mΩ
Certifications：
FCC/UL1973/CE/RoHS
Bluetooth：
No
BMS
BMS：
100A
Max. Continuous Output Power：
1280W
Max. Continuous Charge Current：
100A
Max. Continuous Discharge Current：
100A
Surge Discharge Current (1 Second)：
500A
CHARGE
Charge Method：
CC/CV
Charge Voltage：
14.4V ± 0.2V
Recommend Charge Current：
28A
TEMPERATURE
Charge Temperature：
32℉ to 122℉ (0℃ to 50℃)
Discharge Temperature：
-4℉ to 140℉ (-20℃ to 60℃)
Storage Temperature：
14℉ to 122℉ (-10℃ to 50℃)
Low-Temperature Protection：
32℉ (0℃)
Low-Temperature Charging Protection Auto Recovery：
41℉ (5℃)
OTHERS
Terminals：
M8 bolts
Weight Approx.：
27.9 lbs
Size：
L13 x W6.77 x H8.43 in.
Housing Material：
ABS
Protection Class：
IP65
Product Comparison
Bluetooth
BMS
Max. Continuous Charge Current
Max. Continuous Discharge Current
Surge Discharge Current (1 Second)
Weight Approx.
Size
【🌟Extra 6% Black Friday Deals】Timeusb 12V Lithium Ion Battery 140Ah with Low-Temp Protection
$225.99
$365.99
No
100A
100A
100A
500A
27.9 lbs
L13 x W6.77 x H8.43 in.
【Black Friday Deals】Timeusb 12V 140Ah LiFePO4 Lithium Smart Battery with Bluetooth and Low-Temp Protection
$239.99
$485.99
Yes
150A
140A
150A
700A
28.1 lbs
L13 x W6.77 x H8.5 in.
FAQs
Q: Can I use Timeusb LiFePO4 Lithium batteries as starting batteries?
A:
Timeusb LiFePO4 batteries are intended for energy storage and are not suitable for use as starting batteries. They lack the Cold Cranking Amps (CCA) needed for starting applications.
For more details, please refer to the article "Deep Cycle VS Starting Battery."
Q: Can I use the Timeusb 12V Lithium Ion Battery 140Ah for my trolling motor?
A:
Timeusb lithium ion battery 12V 140Ah is compatible with trolling motor thrust between 30 and 70 lbs. If you have additional questions, we can provide you with recommendations based on your needs.
Q: What is the maximum number of Timeusb 12V 140Ah deep cycle batteries that can be connected?
A:
Timeusb 12V battery supports versatile connections including series, parallel and serial-parallel connections. You can connect up to 4 batteries in series (4S), 4 in parallel (4P) or 16 in series-parallel connection (4P4S).
Q: Can I charge Timeusb 12V Lithium Ion Battery 140Ah in cold weather (under freezing temperatures)?
A:
LiFePO4 batteries can be safely charged between 32°F to 113°F (0°C to 45°C). Timeusb 12V Lithium Ion Batteries 140Ah feature low-temperature charging protection, which automatically stops charging when the cell temperature drops below 32°F. This prevents damage to the battery cells when charging in freezing conditions.
Q: How Long Will a 12V 140Ah Battery Last?
A:
The duration of a 12V 140Ah battery depends on the current drawn and the specific application. You can estimate this using the formula:
Battery life (in hours) = Battery capacity (in amp-hours) / Load current (in amperes)
For example, if we assume a load current of 10 amperes:
Battery life = 140Ah / 10A = 14 hours
For example, with a 10-ampere load, you can expect approximately 14 hours of continuous operation. However, the actual duration may vary based on factors such as system efficiency, fluctuations in load current, and the overall condition of the battery.
